50W Flexible ETFE Panel Portable Bag Mobile USB Charger

50W Flexible ETFE Panel Portable Bag Mobile USB Charger

  • Flexible, and can be properly bent to use a wider range of applications.
    High conversion efficiency, good output efficiency, low light effect,
    light weight, easy to carry, strong applicability.

    With SUNPOWER chip, can be used for car ,home, boat, motorcycle, etc.

    • Item No:FL-50W/20V
    • Size :540*580*3mm
    • Weight:1.23kg
    • Min order:10 pcs
    • Lead time : 15days
    • OEM:Available
    • Original Region:China
    • Maximum power:19.2
    • Panel Efficiency:21-22.5%
    • Soalr cell :A-grade



Product Description

Specification



Electrical Characteristics
Product code FL-50W20V
Maximum power(Pmax) 50W
Voltage at Pmax(Vmp) 19.8
Current at Pmax(Imp) 2.92
Open-circuit voltage(Voc) 23.4
Short -circuit current(Isc) 3.09
Power temperature coefficient -0.38%/ºC
Voltage temperature coefficient -0.27%/ºC
Current temperature coefficient +0.05%/ºC
Cells Efficiency(%) 23.70%
The maximum system voltage 45VDC(IEC)
Output power tolerance ±3%
Cells USA A grade solar cell
No.of cells and connections Module dimension 36(4X9)
Weight 540*580*3mm
Certification 1.23KG CE,RoHS,ISO



Online Customization,We support online customization for the design you want







50W Flexible ETFE Panel Portable Bag Mobile USB Charger



We support custom product packing accroing to your needs

Wooden Box Packing ,Pallet Packing ,Carton packing

Production Process

FAQ

Q1: How to choose the right Panel?
A1: Tell us your demand, then our sales will recommend a suitable panel for you.

Q2: What's the difference between Mono and Poly panel?
A2: Monocrystalline solar panels have the highest efficiency rates since they are made out of the highest-grade silicon.
The process used to make polycrystalline silicon is simpler and costs less. The amount of waste silicon is less compared to monocrystalline.

Q3: How about the delivery time?
A3: 7 days for sample; 15 days for bulk order.

Q4: What is the warranty for solar panels?
A4: 5 years warranty on FGET-Solar product.

Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
