Adopting 210-182mm SMBB (Super Multi BusBar) Monocrystalline Half Cut N-Type Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs
| POWER CLASS | FG-435ND | FG-440ND | FG-445ND | FG-450ND | FG-455ND | |
| STC | STC | STC | STC | STC | ||
| Maximum power (Pmax) | 435W | 440W | 445W | 450W | 455W | |
| Open Circuit Voltage (Voc) | 34.49V | 34.74V | 34.97V | 35.21V | 35.45V | |
| Short Circuit Current (Isc) | 15.84A | 15.90A | 15.96A | 16.02A | 16.08A | |
| Voltage at Maximum power (Vmpp) | 29.43V | 29.65V | 29.87V | 30.08V | 30.29V | |
| Current Maximum Power (Impp) | 14.78A | 14.84A | 14.90A | 14.96A | 15.02A | |
| MODULE EFFICIENCY (%) | 21.77% | 22.02% | 22.27% | 22.52% | 22.77% | |
| STC: Irradiance 1000W/m², cell temperature 25ºC, AM1.5G | ||||||
| BIFACIAL OUTPUT-REARSIDE POWER GAIN | ||||||
5% |
Maximum power (Pmax) | 457W | 462W | 467W | 473W | 478W |
| Module Efficiency STC (%) | 22.86% | 23.12% | 23.38% | 23.65% | 23.91% | |
| 15% | Maximum power (Pmax) | 500W | 506W | 512W | 518W | 523W |
| Module Efficiency STC (%) | 25.04% | 25.32% | 25.61% | 25.90% | 26.19% | |
| 25% | Maximum Power (Pmax) | 544W | 550W | 556W | 563W | 569W |
| Module Efficiency STC (%) | 27.21% | 27.53% | 27.84% | 28.15% | 28.46% | |
Product Size: 1962*1134*30mm
About FGET
Future Green Techonology is committed to creating a green future.
Rooting ourselves in the new energy industry for decade, we manufacturehigh quality solar panel and battery and win high reputation from hundredscustomers globally.
We also have over 100 long-term partners around the world. We sell high-quality batteries and solar panels, and also customize solar panel systems and solar power stations for our customers who need them. If you also want to customize a solar panel system, you can submit your daily electricity consumption requirements below, and we will immediately develop a detailed energy solution for you.
Q1: How to choose the right Panel?
A1: Tell us your demand, then our sales will recommend a suitable panel for you.
Adopting 210-182mm SMBB (Super Multi BusBar) Monocrystalline Half Cut N-Type Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs Item No: FG500-G12 Capacity: 490-510W Cells Number: 108Pcs Min Order: 36 PCS Module Efficiency(%): 22.52% Dimemsions: 1961*1134*34MM Weight: 23.5KG Packing Number: 36Pcs/Pallet 40'HQ Container: 24 Pallets / 864 PCS
Learn More
Adopting 210-182mm SMBB (Super Multi BusBar) Monocrystalline Half Cut N-Type Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs Item No: FG580-G12R Capacity: 565-585W Cells Number: 108Pcs Min Order: 36 PCS Module Efficiency(%): 22.52% Dimemsions: 2279*1134*34MM Weight: 31.5KG Packing Number: 36Pcs/Pallet 40'HQ Container: 20 Pallets / 720 PCS
Learn More
Adopting 210-182mm SMBB (Super Multi BusBar) Monocrystalline Half Cut N-Type Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs Item No: FG450-G12 Capacity: 435-455W Cells Number: 96Pcs Min Order: 36 PCS Module Efficiency(%): 22.52% Dimemsions: 1762*1134*34MM Weight: 21KG Packing Number: 36Pcs/Pallet 40'HQ Container: 26 Pallets/936PCS
Learn More
Adopting 182MM Multi Gate (MBB) Monocrystalline Half Cut N-Type Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs Item No: FG590M Color: Black Min Order: 10 PCS Voltage:43V Module Efficiency(%): 22.84% Dimemsions: 2279*1134*35MM Weight: 28.2KG Packing Number: 36Pcs/Pallet Packing Volume: 3.372CBM/Pallent 40'HQ Container: 620PCS
Learn More
Adopting 182MM Multi Gate (MBB) Monocrystalline Half Cut N-Type Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs Item No: MSD640M Cells Number: 144Pcs Min Order: 10 PCS Voltage: 44.17V Module Efficiency(%): 22.9% Dimemsions: 2464*1134*34MM Weight: 30KG Packing Number: 33Pcs/Pallet Packing Volume: 3.542CBM/Pallent Pallets per container: 16 40'HQ Container: 544PCS
Learn More
Adopting 182MM Multi Gate (MBB) Monocrystalline Half Cut N-Type Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs Item No: MSD440M Cells Number: 108 Pcs Min Order: 36 PCS Voltage: 30.12V Module Efficiency(%): 22.62% Dimemsions: 1724*1134*30MM Weight: 23.9KG Packing Number: 36Pcs/Pallet Packing Volume: 2.834CBM/Pallet 40'HQ Container: 936PCS
Learn More
Adopting 182MM Multi Gate (MBB) Monocrystalline Half Cut N-Type Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs Item No: FG590M Color: Black Min Order: 10 PCS Voltage:43V Module Efficiency(%): 22.84% Dimemsions: 2279*1134*35MM Weight: 28.2KG Packing Number: 36Pcs/Pallet Packing Volume: 3.372CBM/Pallent 40'HQ Container: 720PCS
Learn More
Adopting 182MM Multi Gate (MBB) Monocrystalline Half Cut N-Type Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs Item No: MSD490M Cells Number: 120 Pcs Min Order: 36 PCS Voltage: 36.06V Module Efficiency(%): 22.62% Dimemsions: 1909*1134*35MM Weight: 23.9KG Packing Number: 36Pcs/Pallet Packing Volume: 2.834CBM/Pallet 40'HQ Container: 864PCS
Learn More
